Granite crushing and screening plant
This granite crushing and screening plant is used to crush granite, and the hard stone such as basalt(black.
View details
Crushing & Screening Plants
Aggregates Crushing and Screening
We have rich experience in construction aggregate production and mine crushing. Produce and provide high quality stone crushing equipment and complete sets.
Crushing & Screening Plants
Aggregates Crushing and Screening
We have rich experience in construction aggregate production and mine crushing. Produce and provide high quality stone crushing equipment and complete sets of mature stone crushing solutions.You can read our program cases, or tell us your material types and specific requirements, and customize your own program.
Limestone crushing and screening plant
This limestone crushing and screening plant is used to crush soft or medium hard stone such as: limestone.
View details
Artificial sand making production line
With the reduction of natural sand resources and the advancement of artificial sand crushing equipment.
View details
Aggregate Supply for Ready-Mix
Dedicated crushing and screening circuit sized to feed a batching plant without stockout.
View details
Manufactured Sand Production Line
VSI-based circuit producing specification sand where river sand is unavailable.
View detailsWhat Defines a Good Crushing & Screening Plants
A Aggregates Crushing and Screening turns blasted rock into saleable aggregate. In practice that means a primary crusher that accepts the biggest boulder from the quarry face, a secondary and often tertiary stage that shapes the particles, and screening decks that cut the stream into the size fractions your concrete or asphalt plant actually buys. HAMAC builds each stage — jaw crushers, impact crushers, cone crushers, vertical shaft impact crushers, vibrating screens and feeders — and then integrates them into stationary, modular or crawler-mounted layouts.
The decision that shapes everything downstream is whether the line is stationary, skid-mounted or tracked. A stationary Aggregates Crushing and Screening rewards a fixed quarry with many years of production ahead of it; a tracked or mobile plant pays back where you must follow the face or move between contracts every few months.
Wear parts you can source
Manganese jaw dies, blow bars, mantle and concave sets use common profiles and are stocked for ten years.
True-stage matching
Crusher chamber profile, eccentric throw and screen deck are matched to each other, so no single stage becomes the bottleneck of the whole Aggregates Crushing and Screening.
Spare capacity designed in
Conveyors and screens are sized roughly 15% above nominal so short-term peak demand does not stall the line.
Buying Questions Answered
What output can I realistically expect?
Published figures assume continuous, well-graded feed. In the field, expect 80-90% of nominal throughput; HAMAC quotes conservative rather than theoretical numbers.
Can the plant be upgraded later?
Yes. Conveyors, screen decks and even the tertiary crusher can be added later because we keep the layout modular and reserve structural capacity for it.
How do I choose between a jaw and an impact primary crusher?
A jaw handles abrasive and high-strength rock up to roughly 320 MPa and gives a low wear cost per tonne, while an impact crusher produces a far better particle shape for concrete aggregate but wears faster on hard or abrasive stone.
How much maintenance does the plant need daily?
Roughly 30 minutes: check lubrication pressures, belt tracking, screen mesh tension and hydraulic oil temperature. Weekly items add oil sampling and bolt re-torquing.
Talk to an engineer
Need Help Narrowing Down the Choice?
Send your output requirement and site conditions; we will shortlist the configurations that actually fit.
