Lubrication and monitoring system in concrete mixer
For the lubrication of the whole concrete batching plant, domestic or imported oil are ok. For China brand, we recommend CHANGCHENG. For imported oil, we.
Concrete Mixers
Lubrication and monitoring system in concrete mixer
Wear is the real operating cost. Shaft-end seals, liner plates and mixing arms are therefore designed as replaceable assemblies, dimensioned so that maintenance crews can change them on site within a single shift.
Every cubic metre of structural concrete passes through a Lubrication and monitoring system in concrete mixer. The machine has one job — distribute cement paste evenly around every aggregate particle in the shortest possible cycle — and when it fails, the failure shows up as strength scatter, segregation during pumping or rejected truckloads.
Most enquiries we receive start after a fleet problem — a pump that loses pressure on long booms, a mixer whose drum liners wear prematurely, a batching plant whose weighing tolerance drifts. Each of those has an engineering answer, and that answer belongs in the design stage rather than in the warranty claim.
Key Advantages of Lubrication and monitoring system in concrete mixer
Heavy-duty gearboxes
Planetary gear reducers with forced lubrication are selected for 24/7 duty cycles.
Replaceable wear assemblies
Liners, arms and shaft seals are bolted in; no cutting or welding during routine replacement.
Homogeneity measured, not claimed
Discharge samples tested for strength variance typically fall below 5% across the batch.
Hydraulic or pneumatic discharge
Large-opening gates with adjustable speed prevent segregation at discharge.
Optional tilt/hoist configurations
Available as bare mixer, skip-fed unit, or mounted on a complete plant frame.
Short cycle times
Twin-shaft machines reach full homogeneity in 30-40 seconds, keeping pace with the batching sequence.
Technical Parameters
Indicative ranges for standard configurations. Final values are confirmed against your project requirements.
| Parameter | Specification |
|---|---|
| Mixer type | Twin-shaft / planetary / pan / reversing drum / volumetric |
| Charging capacity | 350 - 6000 litres |
| Output capacity | 250 - 4000 litres per batch |
| Cycle time | 45 - 90 seconds depending on mix |
| Mixing motor power | 11 - 110 kW |
| Discharge | Hydraulic gate / pneumatic gate / reversing drum |
| Liner thickness | 10 - 16 mm wear-resistant plate |
| Drive | Electric motor or diesel engine |
Typical Applications
Field experience across our export markets shows a clear pattern of applications.
Refractory and chemical plants
Planetary mixers for castables, ceramics and specialised mortars
Precast factories
Low-slump and colour-consistent concrete for moulded products
Block and paver yards
Dry-cast pan mixers feeding block-making machines
Batching plants
Central mixing for ready-mix and project plants
Building sites
Skip-hoist and drum mixers for small-batch site production
From Enquiry to Commissioning
Six defined stages, each with named deliverables, so nothing is left to interpretation.
Requirement study
We start with your mix design, hourly output target, aggregate size, jobsite power supply and site layout — not with a catalogue page.
Scheme design
Our engineering team issues a layout drawing, foundation loads, power requirement and an equipment list matched to the target output.
Quotation & contract
A fixed specification quotation with clear technical annexes protects both sides; no vague "standard configuration" wording.
Production & inspection
Weekly production photos, welding and pressure test records, plus third-party inspection if your project requires it.
Delivery & installation
Container or break-bulk shipment, then on-site supervision of assembly, alignment, calibration and dry-run.
After-sales
Remote diagnostics by video call, spare parts dispatch within 48 hours for stocked items, and periodic return visits.
Frequently Asked Questions about Lubrication and monitoring system in concrete mixer
How do I size the mixer to my plant output?
Match batch size to the plant.s rated hourly output divided by the number of batches per hour — normally 40-50 for a twin-shaft installation.
Twin-shaft or planetary?
Twin-shaft wins on throughput and simple maintenance for ready-mix volumes; planetary gives superior homogeneity for low-slump, coloured or fibre-reinforced mixes and is preferred in precast.
How often should liners be replaced?
Typically after 60,000-100,000 batches for a twin-shaft mixer using rounded aggregate; angular or highly abrasive aggregate shortens that.
Can you supply only the mixer to retrofit an existing plant?
Yes. We supply bare mixers with mounting frames, gate actuators and control interfaces for third-party plants.
Is a moisture probe included?
Yes — microwave moisture sensing with automatic water correction is standard on plant-mounted units.
