Fly Ash Brick Making Machine - Block Making Machines
fly ash brick making machine is a Automatic concrete block making equipment. By changing the moulds, it can produce diverse kinds of concrete wall blocks.
Block Making Machines
Fly Ash Brick Making Machine - Block Making Machines
HAMAC builds both egg-layer machines — economical, no pallets, output onto the floor — and full stationary pallet plants with finger cars, elevators and curing racks for higher volume and better surface finish. Mixing is matched to the machine by either a planetary or a pan mixer.
Choosing between them comes down to daily volume target, available floor area, labour cost and how much surface quality your market expects.
Buyers usually compare two things: whether the machine will hold its rated output on a hot day with damp aggregates, and whether anyone will answer the phone in year three. HAMAC designs for both.
Key Advantages of Fly Ash Brick Making Machine
Cycle times near 15 seconds
Well-matched moulds and Servo vibration deliver fast demould without green-product damage.
Consistent compaction
Frequency-controlled vibration plus hydraulic press head ensures uniform density across the whole pallet.
Heavy-duty frame
Stress-relieved welded frames resist the fatigue caused by continuous vibration.
PLC recipe control
Operators select the product and the machine sets vibration, fill time and press parameters automatically.
Quick mould change
Moulds swap in roughly 20 minutes, allowing mixed product runs in one shift.
Ready spare-parts kit
A consumable and wear-parts package ships with every machine to cover the first production months.
Technical Parameters
Indicative ranges for standard configurations. Final values are confirmed against your project requirements.
| Parameter | Specification |
|---|---|
| Model range | QT4-15, QT5-20, QT6-15, QT8-15, QT9-15, QT10-15 and larger |
| Cycle time | 15 - 25 seconds |
| Pallet size | 850 × 550 to 1400 × 900 mm |
| Vibration force | 35 - 120 kN, frequency adjustable |
| Installed power | 25 - 90 kW |
| Products per pallet | 4 - 12 hollow blocks (390×190×190 mm) |
| Control | PLC with touch screen and fault diagnostics |
| Feeding | Belt conveyor from planetary or pan mixer |
Typical Applications
The applications below reflect the situations in which HAMAC customers most commonly deploy it.
Hydraulically pressed slabs
Industrial floors and hard-standing areas
Hollow and solid blocks
Standard masonry units for load-bearing and partition walls
Kerbs and edgings
Road restraint and landscape edging units
Interlocking pavers
Pedestrian and light-traffic paving with colour-layer option
Retaining wall blocks
Segmental units for landscape and road structures
From Enquiry to Commissioning
Six defined stages, each with named deliverables, so nothing is left to interpretation.
Requirement study
We start with your mix design, hourly output target, aggregate size, jobsite power supply and site layout — not with a catalogue page.
Scheme design
Our engineering team issues a layout drawing, foundation loads, power requirement and an equipment list matched to the target output.
Quotation & contract
A fixed specification quotation with clear technical annexes protects both sides; no vague "standard configuration" wording.
Production & inspection
Weekly production photos, welding and pressure test records, plus third-party inspection if your project requires it.
Delivery & installation
Container or break-bulk shipment, then on-site supervision of assembly, alignment, calibration and dry-run.
After-sales
Remote diagnostics by video call, spare parts dispatch within 48 hours for stocked items, and periodic return visits.
Frequently Asked Questions about Fly Ash Brick Making Machine
Do I need pallets?
Egg-layer machines do not use pallets; stationary plants do, and pallet cost and life should be factored into the model comparison.
What about cement content?
Typically 8-12% by weight for hollow blocks depending on the required strength and aggregate quality.
Can I use fly ash instead of cement?
Yes, typically replacing 20-40% of cement by weight, subject to the strength requirement and local standards.
How quickly does it pay back?
Most customers report 8-18 months depending on local block prices, shift pattern and raw material cost.
How much labour is needed?
A semi-automatic line needs about 5-7 people; a fully automatic pallet plant needs 3-4 plus forklift handling.
