M Series Wheeled Skid Steer Loader - Skid Steer Loaders
M series Wheeled Skid Steer Loader is a new generation of small multi-function equipment integrating mechanics, electronics and hydraulics under the.
Skid Steer Loaders
M Series Wheeled Skid Steer Loader - Skid Steer Loaders
A wide attachment catalogue — buckets, pallet forks, hydraulic breakers, augers, trenchers, angle brooms, snow blowers, rock buckets and sweepers — lets one machine cover earthmoving, demolition, landscaping and municipal work.
Vertical-lift geometry suits loading trucks and palletised material because it keeps the load close and high; radial-lift machines dig harder and are generally preferred for backfilling and grading.
Buyers usually compare two things: whether the machine will hold its rated output on a hot day with damp aggregates, and whether anyone will answer the phone in year three. HAMAC designs for both.
Key Advantages of M series Wheeled Skid Steer Loader
Easy daily service
Rear-hinged hood exposes engine, filters and fill points with no tools required.
Versatile ROI
One chassis performing seasonal work keeps utilisation high all year.
Universal attachment coupler
Standard hydraulic coupler accepts HAMAC and common third-party attachments.
Operator comfort
Pressurised cab, air suspension seat, joystick pilot control and rear-view camera option.
High hydraulic flow options
High-flow circuits power cold planers, forestry mulchers and heavy breakers.
Compact turning circle
Zero-radius skid steering works inside buildings, tunnels and congested yards.
Technical Parameters
Indicative ranges for standard configurations. Final values are confirmed against your project requirements.
| Parameter | Specification |
|---|---|
| Rated operating load | 300 - 1500 kg |
| Operating weight | 1.2 - 4.5 tonnes |
| Bucket capacity | 0.2 - 0.6 m³ |
| Engine power | 25 - 75 kW |
| Hydraulic flow | 60 - 140 l/min (high-flow option) |
| Lift geometry | Radial lift / vertical lift |
| Travel speed | Up to 14 km/h (two-speed option) |
| Tyres | Standard / heavy-duty / solid / over-the-tyre track |
Typical Applications
Field experience across our export markets shows a clear pattern of applications.
Agriculture
Feed handling, barn cleaning and field work
Building sites
Material handling, backfilling and site clean-up
Landscaping and roadworks
Grading, trenching and pallet handling
Ports and shipyards
Cargo handling and confined-space cleaning
Demolition interiors
Compact machines working inside structures
From Enquiry to Commissioning
Six defined stages, each with named deliverables, so nothing is left to interpretation.
Requirement study
We start with your mix design, hourly output target, aggregate size, jobsite power supply and site layout — not with a catalogue page.
Scheme design
Our engineering team issues a layout drawing, foundation loads, power requirement and an equipment list matched to the target output.
Quotation & contract
A fixed specification quotation with clear technical annexes protects both sides; no vague "standard configuration" wording.
Production & inspection
Weekly production photos, welding and pressure test records, plus third-party inspection if your project requires it.
Delivery & installation
Container or break-bulk shipment, then on-site supervision of assembly, alignment, calibration and dry-run.
After-sales
Remote diagnostics by video call, spare parts dispatch within 48 hours for stocked items, and periodic return visits.
Frequently Asked Questions about M series Wheeled Skid Steer Loader
What is delivery time?
Standard models ship within 15-25 days; configured machines within 30-40 days.
Radial or vertical lift?
Choose vertical lift for repeated loading into trucks or hoppers; radial lift is better for digging, grading and general-purpose work.
Do you support high-flow hydraulics?
Yes — select models offer high-flow circuits for planers, mulchers and larger breakers.
Is operator training included?
Yes, we provide operating and maintenance training at commissioning or remotely by video.
Can it work inside buildings?
Yes, with low-profile cabs and optional spark arresting mufflers for enclosed spaces.
